Aplicaciones
- Agricultura
- Municipal
- Industrial
- Minería
- Aumentador de presión
- Osmosis Inversa
- Aceite y Gasolina
Características
- Diseño de montaje NEMA de doble brida
- Eje estriado de acero inoxidable
- Sistema de encapsulamiento de seis elementos StatorShield™ de Franklin
- Cojinete de empuje tipo Kingsbury de alta capacidad lubricado por agua
- Llenados en fábrica con la solución de llenado no tóxica, soluble en agua
- Cable reemplazable en campo utilizando la tecnología exclusiva Water Bloc™ de Franklin
- Cubierta externa contra arena en el eje
- Sello mecánico frontal en la salida del eje
- Rotor de barra de cobre
- Están aprobados todos los modelos de los dispositivos de frecuencia variable (DFV)
- Los modelos monofásicos deben utilizarse con una caja de control de Franklin Electric
Ficha Técnica
| Potencia (hp) | Construcción | Volts | Hz | Nº de Cables | Nº de Parte | Empuje | Peso (kg) |
| 7,5 | SAND FIGHTER – C/SUBTROL | 380 | 50 | DOL (3) | 2366118120 | 3500 | 49 |
| SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2367118120 | 3500 | 50 | |
| 316 SS – W/SUBTROL | 380 | 50 | DOL (3) | 2366114020 | 3500 | 48 | |
| 316 SS – W/SUBTROL | 380 | 50 | Y-∆ (6) | 2367114020 | 3500 | 51 | |
| HI-TEMP 90°C | 380 | 50 | DOL (3) | 2766110003 | 4500 | 58 | |
| HI-TEMP 90°C | 380 | 50 | Y-∆ (6) | 2767110003 | 4500 | 60 | |
| HI-TEMP 90°C – 316 SS | 380 | 50 | DOL (3) | 2766113003 | 4500 | 58 | |
| 10 | SAND FIGHTER – C/SUBTROL | 380 | 50 | DOL (3) | 2366128120 | 3500 | 53 |
| SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2367128120 | 3500 | 54 | |
| 316 SS – W/SUBTROL | 380 | 50 | DOL (3) | 2366124020 | 3500 | 52 | |
| 316 SS – W/SUBTROL | 380 | 50 | Y-∆ (6) | 2367124020 | 3500 | 54 | |
| HI-TEMP 90°C | 380 | 50 | DOL (3) | 2766120003 | 4500 | 65 | |
| HI-TEMP 90°C | 380 | 50 | Y-∆ (6) | 2767120003 | 4500 | 68 | |
| HI-TEMP 90°C – 316 SS | 380 | 50 | DOL (3) | 2766123003 | 4500 | 65 | |
| 12,5 | SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2360218120 | 3500 | 53 |
| 15 | SAND FIGHTER – C/SUBTROL | 380 | 50 | DOL (3) | 2366138120 | 3500 | 58 |
| SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2367138120 | 3500 | 59 | |
| 316 SS – W/SUBTROL | 380 | 50 | DOL (3) | 2366134020 | 3500 | 58 | |
| 316 SS – W/SUBTROL | 380 | 50 | Y-▲ (6) | 2367134020 | 3500 | 60 | |
| HI-TEMP 90°C | 380 | 50 | DOL (3) | 2766130003 | 4500 | 70 | |
| HI-TEMP 90°C | 380 | 50 | Y-∆ (6) | 2767130003 | 4500 | 73 | |
| HI-TEMP 90°C – 316 SS | 380 | 50 | DOL (3) | 2766133003 | 4500 | 70 | |
| 20 | SAND FIGHTER – C/SUBTROL | 380 | 50 | DOL (3) | 2366148120 | 3500 | 66 |
| SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2367148120 | 3500 | 67 | |
| 316 SS – W/SUBTROL | 380 | 50 | DOL (3) | 2366144020 | 3500 | 65 | |
| 316 SS – W/SUBTROL | 380 | 50 | Y-∆ (6) | 2367144020 | 3500 | 68 | |
| HI-TEMP 90°C | 380 | 50 | DOL (3) | 2766140003 | 4500 | 78 | |
| HI-TEMP 90°C | 380 | 50 | Y-∆ (6) | 2767140003 | 4500 | 81 | |
| HI-TEMP 90°C – 316 SS | 380 | 50 | DOL (3) | 2766143003 | 4500 | 78 | |
| 25 | SAND FIGHTER – C/SUBTROL | 380 | 50 | DOL (3) | 2366158120 | 3500 | 71 |
| SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2367158120 | 3500 | 72 | |
| 316 SS – W/SUBTROL | 380 | 50 | DOL (3) | 2366154020 | 3500 | 70 | |
| 316 SS – W/SUBTROL | 380 | 50 | Y-∆ (6) | 2367154020 | 3500 | 73 | |
| HI-TEMP 90°C | 380 | 50 | DOL (3) | 2766150103 | 7500 | 91 | |
| HI-TEMP 90°C | 380 | 50 | Y-∆(6) | 2767150103 | 7500 | 93 | |
| HI-TEMP 90°C – 316 SS | 380 | 50 | DOL (3) | 2766153103 | 7500 | 91 | |
| 30 | SAND FIGHTER – C/SUBTROL | 380 | 50 | DOL (3) | 2366168120 | 3500 | 79 |
| SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2367168120 | 3500 | 93 | |
| 316 SS – W/SUBTROL | 380 | 50 | DOL (3) | 2366164020 | 3500 | 78 | |
| 316 SS – W/SUBTROL | 380 | 50 | Y-∆ (6) | 2367164020 | 3500 | 81 | |
| HI-TEMP 90°C | 380 | 50 | DOL (3) | 2766160103 | 7500 | 136 | |
| HI-TEMP 90°C | 380 | 50 | Y-∆ (6) | 2767160103 | 7500 | 138 | |
| HI-TEMP 90°C – 316 SS | 380 | 50 | DOL (3) | 2766163103 | 7500 | 136 | |
| 40 | SAND FIGHTER – C/SUBTROL | 380 | 50 | DOL (3) | 2366178125 | 6000 | 93 |
| SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2367178125 | 6000 | 89 | |
| 316 SS – W/SUBTROL | 380 | 50 | DOL (3) | 2366174025 | 6000 | 91 | |
| 316 SS – W/SUBTROL | 380 | 50 | Y-∆ (6) | 2367174025 | 6000 | 93 | |
| HI-TEMP 90°C | 380 | 50 | DOL (3) | 2766170103 | 7500 | 149 | |
| HI-TEMP 90°C | 380 | 50 | Y-∆ (6) | 2767170103 | 7500 | 151 | |
| HI-TEMP 90°C – 316 SS | 380 | 50 | DOL (3) | 2766173103 | 7500 | 149 | |
| 50 | SAND FIGHTER – C/SUBTROL | 380 | 50 | DOL (3) | 2366188125 | 6000 | 137 |
| SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2367188125 | 6000 | 138 | |
| 316 SS – W/SUBTROL | 380 | 50 | DOL (3) | 2366184025 | 6000 | 136 | |
| 316 SS – W/SUBTROL | 380 | 50 | Y-∆ (6) | 2367184025 | 6000 | 138 | |
| 60 | SAND FIGHTER – C/SUBTROL | 380 | 50 | DOL (3) | 2366198125 | 6000 | 152 |
| SAND FIGHTER – C/SUBTROL | 380 | 50 | Y-∆ (6) | 2367198125 | 6000 | 152 | |
| 316 SS – W/SUBTROL | 380 | 50 | DOL (3) | 2366194025 | 6000 | 149 | |
| 316 SS – W/SUBTROL | 380 | 50 | Y-∆ (6) | 2367194025 | 6000 | 151 |
